Conrad Johnson PV-11L in excellent condition- sounds wonderful. Line stage- very musical and it outshines much more expensive preamps.
PayPal friends and family option only -
Email me at apt_one@yahoo.com
Add $50 for UPS ground shipping within USA
Info-
An improved line stage circuit, incorporating two 12AU7s was introduced in the PV11. Like the PV8, the PV11 features the exclusive use of polypropylene and polystyrene capacitors throughout the audio circuits and related power supplies — no electrolytics are used, even in the main power supply input filter.
The PV11L is a line stage version of the PV11 (without phono stage).
Replacement Tube Set RT11L
V1, V2, V3 & V4: unused | V5, & V6: 12AU7
Features:
Inputs/Outputs
Phono
Tuner
Auxiliary
Tape 1/Tape 2
Two main outputs
Controls:
Selector
Tape 1/Tape 2
Source/Monitor
Mode (Left, Right, Stereo, Reverse, Mono)
Balance
Power
Level
Specifications:
Gain: Phono Stage 47 dB (phono overload 200 mV at 1kHz)
Line Stage: 18 dB
Distortion: less than .1% THD or IMD
Response: bandpass 2Hz to more than 100kHz
RIAA Equalization: +/- .25 dB (20 to 20 kHz)
S/N Ratio: Phono Stage 78 dB below 10 mv input
Line Stage 92 dB below 2.5 volt output
Phase: Line Stage phase inverting, Phono Stage phase correct
Mechanical:
16″ X 3″ x 12.5″ No trades
